Description
Features:
- Dual band dual 1W Gemini Xrossband ExpressLRS transmitters.
- Integrated foldable dual band antennas: Elegant design with foldable antennas for easy transport and storage; Compatible with both 2.4GHz and Sub-G 900MHz frequencies.
- GX01 stabilizers – Full CNC aluminum 3D digital Hall sensor stabilizers.
- 1000Hz digital stabilizers with EdgeTX synchronization.
- Foldable stabilizer sticks for convenient storage and transport.
- Removable switch panels.
- Custom SMA ports: Enjoy antenna installation flexibility with the integration of the SMA port.
- OLED display: Sharp and clear OLED display with high contrast display.
- Internal memory: 512MB integrated high-speed flash memory – no TF cards needed!
- USB-C Connectivity: The GX12 features a single USB-C port that handles smart balanced charging, SIM card connectivity, firmware updates, and direct access to the integrated high-speed flash storage.
- Programmable 6-way switch integration: Individually programmable 6-way switches offer versatile control options tailored to your unique setup.
- Programmable RGB indicators on 6-way and SA/SD switches: Customizable RGB lights provide visual feedback on switch status.
- Powerful and efficient cooling system.
- PCB nano-coating: Built for extreme conditions! The GX12 is built to perform in demanding environments. With thicker plastic and a hydrophobic PCB coating, the controller is designed to withstand hot, cold, dry, and humid environments. You can count on the GX12 to perform wherever your adventures take you!
Specifications:
- Color: Black
- Size: 183*148*78mm
- Weight: 573g
- Frequency: 2.400 GHz and Sub-G 900 MHz
- Internal RF: ELRS 2.4 GHz / Sub-G 900 MHz
- Supported protocols: Express-LRS
- Cooling fan: Yes
- Antenna: Dual foldable 2.4 GHz / Sub-G 900 MHz, omni-directional
- RF: (Dual 1000 mW | Dual band XROSSBAND ELRS)
- Voltage range: 6.6-8.4 V DC
- Current: 390 mA-1000 mA (depending on RF output)
- Radio firmware: EdgeTX (transmitter) / ELRS (RF module)
- Channels: Max 16 channels (depending on receiver)
- Battery: 7.4 V 2-cell lithium polymer / two 3.7V 18650 batteries Li-ion batteries / 21700 5000mAh battery (batteries not included)
- Charging: 2S Smart Balance charging
- Connectivity: USB-C
- Screen: 128*64 black and white OLED display
- Gimbal: GX01 1000Hz, 3D digital CNC Hall effect gimbal with foldable sticks
- Gimbal sticks: 3mm
- External module: Nano / Crossfire compatible
- Update method: USB / EdgeTX Companion PC software
- Memory: 512MB integrated flash memory
